ASUS ZenWiFi AX (XT9) AX7800 Mesh WiFi 6 System Tri-Band Whole-Home - White

Specifications Model ASUS ZenWiFi XT9 Model Name XT9 (W-2-PK) Network Standard IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 Product Segment AX7800 ultimate AX performance : 574+2402+4804Mbps WiFi Data Rate 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) (1024QAM) : up to 4333 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz-1) : up to 2402 Mbps WiFi 6 (802.11ax) (5GHz-2) : up to 4804 Mbps Antenna Internal antenna x 6 Transmit / Receive 2.4GHz 2x2 5GHz-1 2x2 5GHz-2 4x4 Processor 1.7 GHz quad-core processor Memory 256 MB Flash 512 MB RAM Boosts Speed OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth * The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions. Operating Frequency 2.4G Hz, 5 GHz-1, 5 GHz-2 Operating Mode Wireless router mode Access point mode I/O Ports RJ45 for 2.5G BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3 USB 3.2 Gen 1 x 1 Buttons WPS Button, Reset Button, Power Switch LED Indicator Power x 1 Power Supply AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 3 A current
